McIntosh 75

  • Descripción

Descripción

ELECTRICAL: 75w. Response: 18-40kHz (+0 -1.0dB). Distortion 0.5%. Noise & hum -90dB. Output impedance: 4, 8, 16, 67, 150 and 600 ohms. All outputs isolated from ground. Output voltages 25, 70.7, 115 and 230V. Internal impedance 8% of rated impedance. Input impedance 250k. Input sensitivity 0.5V.

MECHANICAL: Grey hammertone chassis. All output impedance and voltage connections at octal socket or barrier strip. Line voltage switch: 220V. Audio input.

FRONT PANEL: Gain control. Power switch: on or off. Fuse. Pilot light-red.

TUBES: 2-KT88/6550 output, 12AX7, 12AU7, 12BH7, 12AT7/12AZ7. Solid state rectifier.

Size 8-3/4"H, 19"W (for rack mounting) and 7-3/4"D. Weight 50 lb. Sold from 1961-1971

7/10 = Good; 2-3 Minor Scratches; Used but Cared For
7/10 = Bueno, 2 o 3 rayadas, usado pero en buen estado

Ask for price

Consultar precio
